טבלת גיאומטריה - POLYGON KALOSI V3 ST
נתוני גיאומטריה לפי מידה - Low Step
| Geometry | S | M |
| Height (cm) | 150-160 | 160-170 |
| Seat Tube Length (A) | 460 | 500 |
| Seat Tube Angle (B) | 74° | 74° |
| Effective Seat Tube Angle (C) | 74° | 74° |
| Head Tube Length (D) | 165 | 165 |
| Head Tube Angle (E) | 69° | 69° |
| Effective Top Tube (F) | 585 | 600 |
| BB Height (G) | 298 | 298 |
| BB Offset (H) | 60 | 60 |
| Chainstay Length (I) | 480 | 480 |
| Wheelbase (J) | 1148 | 1163 |
| Frame Reach (K) | 394 | 409 |
| Frame Stack (L) | 666 | 666 |
| Standover Height (M) | 609 | 595 |
S
Height (cm)150-160
Seat Tube Length (A)460
Seat Tube Angle (B)74°
Effective Seat Tube Angle (C)74°
Head Tube Length (D)165
Head Tube Angle (E)69°
Effective Top Tube (F)585
BB Height (G)298
BB Offset (H)60
Chainstay Length (I)480
Wheelbase (J)1148
Frame Reach (K)394
Frame Stack (L)666
Standover Height (M)609
M
Height (cm)160-170
Seat Tube Length (A)500
Seat Tube Angle (B)74°
Effective Seat Tube Angle (C)74°
Head Tube Length (D)165
Head Tube Angle (E)69°
Effective Top Tube (F)600
BB Height (G)298
BB Offset (H)60
Chainstay Length (I)480
Wheelbase (J)1163
Frame Reach (K)409
Frame Stack (L)666
Standover Height (M)595
הנתונים במ"מ אלא אם צוין אחרת. מומלץ לוודא התאמת מידה סופית לפי גובה, סגנון רכיבה והעדפה אישית.
