טבלת גיאומטריה - POLYGON CASCADE 3
נתוני גיאומטריה לפי מידה - S 27.5 / M-XL 29
| Geometry | S 27.5" | M 29" | L 29" | XL 29" |
| A Seat Tube Length | 390 | 430 | 460 | 491 |
| B Seat Tube Angle | 75 | 75 | 75 | 75 |
| C Effective Seat Tube Angle | 75 | 75 | 75 | 75 |
| D Head Tube Length | 115 | 95 | 100 | 110 |
| E Head Tube Angle | 68 | 68 | 68 | 68 |
| F Effective Top Tube | 561 | 585 | 604 | 624 |
| G BB Height | 310 | 303 | 304 | 304 |
| H BB Offset | -45 | -69 | -69 | -69 |
| I Chainstay Length | 440 | 455 | 455 | 455 |
| J Wheelbase | 1108 | 1142 | 1161 | 1182 |
| K Frame Reach | 400 | 420 | 440 | 453 |
| L Frame Stack | 601 | 624 | 629 | 638 |
| M Standover Height | 703 | 737 | 759 | 780 |
S 27.5"
A Seat Tube Length390
B Seat Tube Angle75
C Effective Seat Tube Angle75
D Head Tube Length115
E Head Tube Angle68
F Effective Top Tube561
G BB Height310
H BB Offset-45
I Chainstay Length440
J Wheelbase1108
K Frame Reach400
L Frame Stack601
M Standover Height703
M 29"
A Seat Tube Length430
B Seat Tube Angle75
C Effective Seat Tube Angle75
D Head Tube Length95
E Head Tube Angle68
F Effective Top Tube585
G BB Height303
H BB Offset-69
I Chainstay Length455
J Wheelbase1142
K Frame Reach420
L Frame Stack624
M Standover Height737
L 29"
A Seat Tube Length460
B Seat Tube Angle75
C Effective Seat Tube Angle75
D Head Tube Length100
E Head Tube Angle68
F Effective Top Tube604
G BB Height304
H BB Offset-69
I Chainstay Length455
J Wheelbase1161
K Frame Reach440
L Frame Stack629
M Standover Height759
XL 29"
A Seat Tube Length491
B Seat Tube Angle75
C Effective Seat Tube Angle75
D Head Tube Length110
E Head Tube Angle68
F Effective Top Tube624
G BB Height304
H BB Offset-69
I Chainstay Length455
J Wheelbase1182
K Frame Reach453
L Frame Stack638
M Standover Height780
הנתונים במ"מ אלא אם צוין אחרת. מומלץ לוודא התאמת מידה סופית לפי גובה, סגנון רכיבה והעדפה אישית.
