טבלת גיאומטריה - POLYGON CASCADE 2
נתוני גיאומטריה לפי מידה - S/M בלבד
| Geometry | S | M |
| Height | 155-165 cm | 165-175 cm |
| A Seat Tube Length | 390 | 430 |
| B Seat Tube Angle | 75° | 75° |
| C Effective Seat Tube Angle | 75° | 75° |
| D Head Tube Length | 115 | 120 |
| E Head Tube Angle | 68° | 68° |
| F Effective Top Tube | 561 | 582 |
| G BB Height | 310 | 310 |
| H BB Offset | -45 | -45 |
| I Chainstay Length | 440 | 440 |
| J Wheelbase | 1108 | 1129 |
| K Frame Reach | 400 | 420 |
| L Frame Stack | 601 | 606 |
| M Standover Height | 704 | 734 |
S
Height155-165 cm
A Seat Tube Length390
B Seat Tube Angle75°
C Effective Seat Tube Angle75°
D Head Tube Length115
E Head Tube Angle68°
F Effective Top Tube561
G BB Height310
H BB Offset-45
I Chainstay Length440
J Wheelbase1108
K Frame Reach400
L Frame Stack601
M Standover Height704
M
Height165-175 cm
A Seat Tube Length430
B Seat Tube Angle75°
C Effective Seat Tube Angle75°
D Head Tube Length120
E Head Tube Angle68°
F Effective Top Tube582
G BB Height310
H BB Offset-45
I Chainstay Length440
J Wheelbase1129
K Frame Reach420
L Frame Stack606
M Standover Height734
הנתונים במ"מ אלא אם צוין אחרת. מומלץ לוודא התאמת מידה סופית לפי גובה, סגנון רכיבה והעדפה אישית.
