טבלת גיאומטריה - MARIN Ella Valley 29
נתוני גיאומטריה לפי מידה
| Geometry | M | L | XL |
| A Stack | 622 | 626 | 631 |
| B Reach | 445 | 465 | 485 |
| C Headtube Angle | 67° | 67° | 67° |
| D Headtube Length | 110 | 115 | 120 |
| E Seattube Length | 431 | 481 | 520 |
| F Seattube Angle | 74.5° | 74.5° | 74.5° |
| G Toptube Effective | 617 | 639 | 660 |
| H BB Height | 311.5 | 311.5 | 311.5 |
| I BB Drop | 61 | 61 | 61 |
| J Chainstay | 455 | 455 | 455 |
| K Wheelbase | 1184 | 1206 | 1228 |
| L Standover Height | 699 | 726 | 760 |
| M Fork Offset | 46 | 46 | 46 |
| N Seatpost Diameter | 27.2 | 27.2 | 27.2 |
| O Handlebar Width | 780 | 780 | 780 |
| P Stem Length | 45 | 45 | 45 |
| Q Crank Length | 170 | 170 | 170 |
M
A Stack622
B Reach445
C Headtube Angle67°
D Headtube Length110
E Seattube Length431
F Seattube Angle74.5°
G Toptube Effective617
H BB Height311.5
I BB Drop61
J Chainstay455
K Wheelbase1184
L Standover Height699
M Fork Offset46
N Seatpost Diameter27.2
O Handlebar Width780
P Stem Length45
Q Crank Length170
L
A Stack626
B Reach465
C Headtube Angle67°
D Headtube Length115
E Seattube Length481
F Seattube Angle74.5°
G Toptube Effective639
H BB Height311.5
I BB Drop61
J Chainstay455
K Wheelbase1206
L Standover Height726
M Fork Offset46
N Seatpost Diameter27.2
O Handlebar Width780
P Stem Length45
Q Crank Length170
XL
A Stack631
B Reach485
C Headtube Angle67°
D Headtube Length120
E Seattube Length520
F Seattube Angle74.5°
G Toptube Effective660
H BB Height311.5
I BB Drop61
J Chainstay455
K Wheelbase1228
L Standover Height760
M Fork Offset46
N Seatpost Diameter27.2
O Handlebar Width780
P Stem Length45
Q Crank Length170
הנתונים במ"מ אלא אם צוין אחרת. הגיאומטריה מבוססת על טבלת MARIN הרשמית לדגם Bolinas Ridge 2 29, שתואם לפלטפורמת Ella Valley 29. מומלץ לוודא התאמת מידה סופית לפי גובה, סגנון רכיבה והעדפה אישית.
