טבלת גיאומטריה - MARIN Ella Valley 27.5
נתוני גיאומטריה לפי מידה
| Geometry | XS | S | M |
| A Stack | 622 | 626 | 631 |
| B Reach | 445 | 465 | 485 |
| C Headtube Angle | 67° | 67° | 67° |
| D Headtube Length | 110 | 115 | 120 |
| E Seattube Length | 431 | 481 | 520 |
| F Seattube Angle | 74.5° | 74.5° | 74.5° |
| G Toptube Effective | 617 | 639 | 660 |
| H BB Height | 311.5 | 311.5 | 311.5 |
| I BB Drop | 61 | 61 | 61 |
| J Chainstay | 455 | 455 | 455 |
| K Wheelbase | 1184 | 1206 | 1228 |
| L Standover Height | 699 | 726 | 760 |
| M Fork Offset | 46 | 46 | 46 |
| N Seatpost Diameter | 27.2 | 27.2 | 27.2 |
| O Handlebar Width | 780 | 780 | 780 |
| P Stem Length | 45 | 45 | 45 |
| Q Crank Length | 170 | 170 | 170 |
XS
A Stack622
B Reach445
C Headtube Angle67°
D Headtube Length110
E Seattube Length431
F Seattube Angle74.5°
G Toptube Effective617
H BB Height311.5
I BB Drop61
J Chainstay455
K Wheelbase1184
L Standover Height699
M Fork Offset46
N Seatpost Diameter27.2
O Handlebar Width780
P Stem Length45
Q Crank Length170
S
A Stack626
B Reach465
C Headtube Angle67°
D Headtube Length115
E Seattube Length481
F Seattube Angle74.5°
G Toptube Effective639
H BB Height311.5
I BB Drop61
J Chainstay455
K Wheelbase1206
L Standover Height726
M Fork Offset46
N Seatpost Diameter27.2
O Handlebar Width780
P Stem Length45
Q Crank Length170
M
A Stack631
B Reach485
C Headtube Angle67°
D Headtube Length120
E Seattube Length520
F Seattube Angle74.5°
G Toptube Effective660
H BB Height311.5
I BB Drop61
J Chainstay455
K Wheelbase1228
L Standover Height760
M Fork Offset46
N Seatpost Diameter27.2
O Handlebar Width780
P Stem Length45
Q Crank Length170
הנתונים במ"מ אלא אם צוין אחרת. הגיאומטריה מבוססת על טבלת MARIN הרשמית לדגם Bolinas Ridge 2, שתואם לפלטפורמת Ella Valley 27.5. מומלץ לוודא התאמת מידה סופית לפי גובה, סגנון רכיבה והעדפה אישית.
