טבלת גיאומטריה - MARIN DS-X FS 2026
נתוני גיאומטריה לפי מידה
| Geometry | M | L | XL |
| A Stack | 601.8 | 629.7 | 657.6 |
| B Reach | 425 | 440 | 455 |
| C Headtube Angle | 68.5° | 68.5° | 68.5° |
| D Headtube Length | 120 | 150 | 180 |
| E Seattube Length | 480 | 520 | 558 |
| F Seattube Angle | 74° | 74° | 74° |
| G Toptube Effective | 597.6 | 620.6 | 643.6 |
| H BB Height | 277.5 | 277.5 | 277.5 |
| I BB Drop | 82 | 82 | 82 |
| J Chainstay | 425 | 425 | 425 |
| K Wheelbase | 1097.3 | 1123.3 | 1149.3 |
| L Standover Height | 708 | 738 | 741.7 |
| M Fork Offset | 47 | 47 | 47 |
| N Seatpost Diameter | 27.2 | 27.2 | 27.2 |
| O Handlebar Width | 680 | 680 | 700 |
| Stem Length | 70 | 70 | 70 |
| Crank Length | 175 | 175 | 175 |
M
A Stack601.8
B Reach425
C Headtube Angle68.5°
D Headtube Length120
E Seattube Length480
F Seattube Angle74°
G Toptube Effective597.6
H BB Height277.5
I BB Drop82
J Chainstay425
K Wheelbase1097.3
L Standover Height708
M Fork Offset47
N Seatpost Diameter27.2
O Handlebar Width680
Stem Length70
Crank Length175
L
A Stack629.7
B Reach440
C Headtube Angle68.5°
D Headtube Length150
E Seattube Length520
F Seattube Angle74°
G Toptube Effective620.6
H BB Height277.5
I BB Drop82
J Chainstay425
K Wheelbase1123.3
L Standover Height738
M Fork Offset47
N Seatpost Diameter27.2
O Handlebar Width680
Stem Length70
Crank Length175
XL
A Stack657.6
B Reach455
C Headtube Angle68.5°
D Headtube Length180
E Seattube Length558
F Seattube Angle74°
G Toptube Effective643.6
H BB Height277.5
I BB Drop82
J Chainstay425
K Wheelbase1149.3
L Standover Height741.7
M Fork Offset47
N Seatpost Diameter27.2
O Handlebar Width700
Stem Length70
Crank Length175
הנתונים במ"מ אלא אם צוין אחרת. מומלץ לוודא התאמת מידה סופית לפי גובה, סגנון רכיבה והעדפה אישית.
