טבלת גיאומטריה - POLYGON IMPRESSION AX DISC
נתוני גיאומטריה לפי מידה
| SIZE | M |
| A Seat Tube Length | 430 |
| B Seat Tube Angle | 73° |
| C Effective Seat Tube Angle | 73° |
| D Head Tube Length | 120 |
| E Head Tube Angle | 71° |
| F Effective Top Tube | 590 |
| G BB Height | 300 |
| H BB Offset | 50 |
| I Chainstay Length | 460 |
| J Wheelbase | 1795 |
| K Frame Reach | 420 |
| L Frame Stack | 555 |
| M Standover Height | 726 |
M
A Seat Tube Length430
B Seat Tube Angle73°
C Effective Seat Tube Angle73°
D Head Tube Length120
E Head Tube Angle71°
F Effective Top Tube590
G BB Height300
H BB Offset50
I Chainstay Length460
J Wheelbase1795
K Frame Reach420
L Frame Stack555
M Standover Height726
הנתונים במ"מ אלא אם צוין אחרת. מומלץ לוודא התאמת מידה סופית לפי גובה, סגנון רכיבה והעדפה אישית.
